TechWin Relay Server
Windows service that acts as an HTTP relay, forwarding IP camera requests to configurable destinations with transparent authentication and centralized management via graphical interface.
TechWin Systems Relay Service is a Windows service that functions as an HTTP intermediary between IP cameras and destination systems. It allows flexible mapping configuration between origin IDs and destination URLs, maintaining original authentication and forwarding all requests transparently.
Includes a system tray management application with graphical interface to configure mappings, view real-time logs, and manage licenses. Ideal for multi-camera integration scenarios where centralized and controlled HTTP traffic redirection is required.
Licensing is based on the number of active mappings. The base plan includes up to 8 mappings, and for higher quantities we apply progressive volume discounts, reducing the cost per mapping as your deployment grows. This lets you start with a lower initial investment and scale with better cost efficiency.
Native Windows service with automatic startup
HTTP relay with full GET/POST/PUT/DELETE method support
Configurable mapping of origin IDs to destination URLs
Transparent Basic authentication passthrough
Automatic configuration reload without service restart
Graphical interface via system tray for complete management
Visual mapping editor with real-time validation
Log viewer with automatic tail and synchronized scrolling
Service state control (start/stop) directly from interface
Structured logs with daily rotation and configurable retention
Support for multiple channels per license
Real-time status notifications
High-performance asynchronous architecture
Technical Requirements
Operating System: Windows Server 2016 or higher, Windows 10/11 (64-bit)
Framework: .NET Framework 4.8 or higher
Privileges: Account with administrative permissions for Windows service installation and management;
Network: TCP port 5500 available (configurable)
Storage: Minimum 50 MB free disk space for application and logs
RAM: Minimum 512 MB available
License: Valid TechWin license required for service operation
